AVR D550

Price 89995.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Piece

AVR D550 Specification

Power Rating
8 A rated excitation current at 55 C

Output Current
8 A DC Ampere (amp)

Input Voltage
50 277 V AC Volt (V)

Output Voltage
Variable DC excitation voltage, dependent on the alternator excitation system and operating conditions. Volt (V)

Efficiency
N/A

Frequency (MHz)
50/60 Hertz (HZ)

Warranty
12 MONTH

Current
8, C, , A, , D Ampere (amp)

Usage & Applications
The Leroy-Somer / Nidec D550 Digital Automatic Voltage Regulator (AVR) is used to control and maintain the output voltage of compatible synchronous alternators by regulating excitation current. Applications: - Industrial diesel generator sets and standby power systems. - Power plants and industrial power generation equipment. - Commercial and institutional backup power supplies. - Synchronous alternators used in industrial facilities. - Generator voltage stabilization under varying electrical loads. - Alternator excitation control and voltage adjustment. - Generator commissioning, monitoring, and maintenance. - Compatible SHUNT, AREP, and PMG excitation systems.

Rated Voltage
50 277 V AC Volt (V)

Operating Temperature
40 C to +70 C Celsius (oC)

Weight
0.8 Kilograms (kg)

Cable Type
Multicore insulated copper control cable and power wiring, selected according to the terminal function and manufacturer s wiring diagram.

Ambient Temperature
40 C to +70 C. Celsius (oC)

Display Type
Digital

Phase
3-Phase

Degree of Protection
IP00

Frequency
50/60 Hertz (HZ)

Features
Digital automatic voltage regulation High voltage regulation accuracy Supports SHUNT, AREP, and PMG excitation systems Adjustable voltage and excitation parameters Generator monitoring and diagnostic functions Configurable protection features USB and CAN J1939 communication capabilities PC-based configuration using compatible software Suitable for compatible industrial alternators and generator sets

Conductor
Copper

Rated Current
8 A Ampere (amp)

Material
Industrial-grade electronic components with a metal heat sink and insulated housing. Exact housing and internal material specifications are manufacturer-dependent.

Control System
Digital electronic, microprocessor-based automatic voltage regulation system.

Usage
SVC

Design
Digital electronic, microprocessor-based automatic voltage regulator with a compact industrial design for alternator excitation control.

Insulation Resistance
N/A

Voltage Protection
Overvoltage protection and configurable voltage monitoring, depending on settings and system configuration

Display
Other

Dimension (L*W*H)
20 15 5 cm Centimeter (cm)

Rated Power
N/A

Current Type
AC

Waveform Distortion
N/A

Product Type
Digital Automatic Voltage Regulator (AVR) for synchronous alternators and generator sets.

AVR D550 Trade Information

Minimum Order Quantity
1 Piece

Delivery Time
1 Week

About AVR D550

The Leroy-Somer D550 Digital Automatic Voltage Regulator (AVR) is an advanced electronic control device designed to maintain stable and precise output voltage in synchronous alternators and industrial generator sets. It automatically adjusts the alternator excitation current in response to variations in electrical load, helping to ensure reliable power generation and consistent voltage performance.

The D550 supports multiple excitation configurations, including SHUNT, AREP, and PMG, depending on the alternator design. It provides digital voltage regulation, configurable operating parameters, monitoring functions, and protective features to support safe and efficient generator operation.

The regulator offers advanced configuration and diagnostic capabilities through compatible software, facilitating commissioning, maintenance, and troubleshooting. Its communication capabilities support integration with compatible generator control and monitoring systems.

The D550 is suitable for industrial power plants, commercial power generation, standby generator systems, and other applications requiring precise voltage regulation, operational reliability, and dependable alternator excitation control.

Key features

Accurate voltage regulation: Maintains stable alternator output voltage as electrical loads change.
Digital control: Enables configuration and adjustment of regulator parameters.
Multiple excitation options: Compatible with SHUNT, AREP, and PMG systems, subject to alternator specifications.
Generator protection: Supports configurable protective functions against specified abnormal operating conditions.
Monitoring and diagnostics: Facilitates system adjustment, fault investigation, and maintenance.
Industrial application: Suitable for compatible synchronous alternators used in continuous-duty and standby power systems.
Commissioning support: Allows operating parameters to be configured using compatible software.
Reliable operation: Helps maintain consistent generator performance during changing load conditions.

Product: Digital Automatic Voltage Regulator (AVR) Brand: Leroy-Somer / Nidec Model: D550 Application: Alternator excitation and generator output voltage regulation Product category: Generator AVR / Digital Voltage Regulator
